Banana Pi BPI-R3 Open Source Router Board Wi-Fi 6 & Dual Fiber SFP Ports

  • $103.96
  • Banana Pi BPI-R3 Open Source Router Board Wi-Fi 6 & Dual Fiber SFP Ports

    Banana Pi BPI-R3 Router board with MediaTek MT7986(Filogic 830) quad-core ARM A53 + MT7531A chip design,2G DDR RAM, and 8G eMMC flash onboard, It is a very high-performance open-source router development board, that supports Wi-Fi 6/6E 2.4G wifi use MT7975N and 5G wifi use MT7975P, support 2 SFP 2.5GbE port, and 5 GbE network port.

    MediaTek MT7986(Filogic 830)

    The MT7986(Filogic 830) integrates four Arm Cortex-A53 cores up to 2GHz with up to 18,000 DMIPs of processing power and 6Gbps of dual 4x4 Wi-Fi 6/6E connectivity. It has two 2.5g Ethernet interfaces and serial peripheral interfaces (SPI). Filogic 830‘s built-in hardware acceleration engine enables fast and reliable Wi-Fi offloading and wireless network connection. In addition, the chip supports Mediatek FastPath™ technology, which is suitable for games, AR/VR, and other low-latency applications.

    Wi-fi 6E has many advantages over its predecessors, including lower latency, larger bandwidth capacity, and faster transmission rates. Wireless network devices supporting the 6GHz band mainly use 160MHz wide channel and 6GHz uncongested bandwidth to provide multigigabit transmission and low-latency wi-fi connection, providing a reliable wireless network for streaming media, games, AR/VR, and other applications.

    Application direction

    Internet service Router

    Wireless Router

    Wireless Repeater

    Home security Gateway

    Home Automation

    Nas device

    Network and communication applications

    Key Features

    MediaTek MT7986(Filogic 830) Quad-core ARM Cortex A53+MT7531 chip design

    Wifi 6/6E 4x4 2.4G Wifi(MT7975N) +4x4 5G Wifi(MT7975P)

    2G DDR RAM

    8G eMMC flash

    2 SFP 2.5GbE

    5 GbE network port

    PoE support

    Mini PCIe via USB

    M.2 KEY-E PCIe interface

    Micro SD Card Interface

    26 PIN GPIO

    Jumper setting

    Jumper Setting of Banana pi BPI-R3
    Jumper SettingSW1SW2SW5SW6
    SPIM-NoRLowLowLowX
    SPIM-NandHighLowHighX
    eMMCLowHighXLow
    SD cardHighHighXHigh

    Hardware spec

    HardWare Specification of Banana pi BPI-R3
    CPUMediaTek MT7986(Filogic 830) Quad-core ARM Cortex A53+MT7531 chip design
    SDRAM2 GB LPDDR3
    On board StorageMicroSD \(TF\) card,8GB eMMC onboard
    GPIO26 Pin GPIO, some of which can be used for specific functions including UART, I2C, SPI, PWM, and I2S.
    On board Network5 Port 10/100/1000Mbps Ethernet
    SFP2 SFP 2.5GbE
    WifiWifi 6/6E 4x4 2.4G Wifi(MT7975N) +4x4 5G Wifi(MT7975P)
    Mini PCI-EMini PCIe via USB
    M.2 interfaceM.2 KEY-M PCIe Interface
    USB1 USB 3.0 Host, 2 USB Interface With Slot.
    ButtonsReset button, WPS button, Boot switch
    LEDsPower status Led and RJ45 Led
    DC Power12V/2A with DC-in
    Sizes100.5x148mm same as Banana Pi BPI-R64 and Banana Pi BPI-R2
    WeightApprox. 200gr


    • 2 or more $102.27
    • 4 or more $100.86
    • Brand: Banana PI
    • Product Code: bpi-r3
    • Availability: 35
