Banana Pi BPI-W3 RK3588 Quad Core LPDDR4 8G RAM 32G eMMC 2.5Gbps Ethernet Single Board Computer
$173.04
- Brand: Banana PI
- Product Code: bpi-w3
- Availability: In Stock
- Ex Tax: $173.04
-
- 2 or more $171.11
- 4 or more $169.62
Banana Pi BPI-W3 Rockchip RK3588 Quad Core A76 + Quad Core A55 LPDDR4 8G RAM 32G eMMC 2.5Gbps Ethernet Single Board Computer
About this item
SOC: RockChip RK3588
CPU:Quad Core A76+ Quad Core A55,use 8nm , 2.4GHz
GPU:ARM Mali-G610 MP4 GPU,Support OpenGL ES3.2/OpenCL 2.2/Vulkan1.1, 450 GFLOPS
Product Description
Hardware specs
SOC: RockChip RK3588
CPU:Quad Core A76+ Quad Core A55,use 8nm , 2.4GHz
GPU:ARM Mali-G610 MP4 GPU,Support OpenGL ES3.2/OpenCL 2.2/Vulkan1.1, 450 GFLOPS
NPU:6 TOP S, Support INT4/INT8/INT16 mixed operation, Support framework switching of TensorFlow/MXNet/PyTorch/Caffe
Incode&Decode: incode:8K@60fps H.265/VP9/AVS2,8K@30fps H.264 AVC/MVC,4K@60fps AV1,1080P@60fps MPEG-2/-1/VC-1/VP8,decode:8K@30fps H.265/H.264
Ram:4GB/8GB/16GB(up to 32GB)64bit LPDDR4/LPDDR4x/LPDDR5,Defalut LPDDR4 8GB
Flash: 16 GB/32GB/64GB/128GB/256GB eMMC, supports MicroSD card slot, Defaut:32GB
M2 Key M: The interface supports an extension SSD
Network:2.5G Network interface(rtl8125)
Video Output:2x HDMI2.1(just one support 8K@60fps or 4K@120fps,other support 4K@60fps),1 x MIPI-DSI(4K@60fps),1 x DP1.4(8K@30fps)
Video Input:1x 4Lanes MIPI CSI / 2 x 2lanes MIPI CSI,1 x HDMI RX2.0
Voice:2x HDMI voice output ,1 x DP1.4 voice output,1 x headphone (es8316)
Wireless:M2 E key interface support sdio,pcie,usb BT&wifi(AP6256,Intel AX210)
USB:2x USB3.1,2 x USB2.0,1x USB-C(DP1.4(8K@30fps)/OTG/PD fast charging)
Others: Fan, RTC, LED, debug
Button: Power Button, Reset Button, Recovery Button, Root Button
GPIO:40x GPIO(UART,SPI,I2C,I2S,PWM,ADC, GPIO, 5V power ,3.3V power)
Power:DC 12V/2.5A Aperture 2.5mm,Support USB Type-C PD 2.0 ,9V/2A, 12V/2A, 15V/2A,Support 12V POE
System: Android 12.0, Ubuntu, Debian 11, Buildroot, Kirin Linux
Size:148 mm × 100.5mm
Operating Temperature:-10℃ ~ 70℃
Storage Temperature:-20℃ ~ 70℃
Documents
Rockchip RK3588 datasheet
Baidu cloud: https://pan.baidu.com/s/1GeskKfLFwjgmz0pgt7sICg?pwd=8888 (pincode:8888)
Google Drive: https://drive.google.com/drive/folders/1l1YmUdBaLuDkJma3CYZJWjYug9D-jV_4?usp=sharing
Banana PI BPI-W3 SCH, DXF, SMD file
Baidu cloud: https://pan.baidu.com/s/1ETL7U4R54Cd5cDg8usp-JQ?pwd=pb48 (pincode:8888)
Google Drive: https://drive.google.com/drive/folders/1d_vtW5aDH3dPAco-dHIwm16r25JUYWS8?usp=sharing
Banana Pi BPI-W3 coare board 3588-LGA Core board all pin list file(5.core board (LGA) pin List)
Baidu cloud: https://pan.baidu.com/s/1ZqDRkk0NVEjpHxsQNHbleQ?pwd=8888 (pincode:8888)
Google Drive: https://docs.google.com/spreadsheets/d/1yj6fLbJET5cLjJG-cD3R5_b7S4umTFXI/edit?usp=sharing&ouid=101692257577438398584&rtpof=true&sd=true
Banana Pi Core board design for RK3588: BPI-RK3588 Core board and development Kit
Rockchip RK3588 datasheet :https://drive.google.com/file/d/1KAq1_kKqPtkq8Vlq-h_yUPUZLrgqSKHI/view?usp=sharing
Banana Pi BPI-W3 RK3588 NPU6T AI RKNN Toolkit2 and RKNPU2 demo ：https://www.youtube.com/watch?v=AEU87YUZz8Y
BPI-W3 Rk3588 development github blog: https://github.com/ArmSoM/Embedded-Technology-Blog
BPI-W3 Ubuntu 20.04 Linux system adaptation is complete:https://www.youtube.com/watch?v=xVDkWv_Q9xY
Image Release
Android
BPI-W3_armsom-w3-emmc-android12-rkr12-20231103.img
Baidu cloud: https://pan.baidu.com/s/1rAfTRARQRDwaZnulPOu0Fg?pwd=8888 (pincode:8888)
Google Drive: https://drive.google.com/file/d/1y_tEuc0rslUtNn4SVZoyPTh9tAqAcKp4/view?usp=sharing
BPI-W3_armsom-w3-emmc-android12-TV-rkr12-20230525.img
Baidu cloud: https://pan.baidu.com/s/1p8gOK3gNTN-f0Fxb6c6CFw?pwd=8888 (pincode:8888)
Linux
Armbian
Ubuntu
ubuntu-22.04.3-preinstalled-desktop-arm64-bpi-w3_armsom-w3.img
Baidu Cloud: https://pan.baidu.com/s/1lKyEvNJXKkf13xwDg1e4Hw?pwd=8888 (pincode:8888)
Google Drive: https://drive.google.com/drive/folders/162vkWVjWJCsPRG7XjONzCIkdPkro5zY1?usp=sharing
ubuntu-22.04.3-preinstalled-server-arm64-bpi-w3_armsom-w3.img
Baidu cloud: https://pan.baidu.com/s/1cqbpgk5ykp_-1uv9ZpxoZg?pwd=8888 (pincode:8888)
Google drive: https://drive.google.com/drive/folders/1-GxlXelKY11b-sbiNARzA0DZ-bb328l-?usp=sharing
Debian
BPI-W3_armsom-w3-debian-bullseye-xfce4-arm64-20231204.img
Baidu cloud: https://pan.baidu.com/s/1OB6qzCmwhaXTnabs0_jmeQ?pwd=8888 (pincode:8888)
Google Drive: https://drive.google.com/drive/folders/1E9ynf6LSThnb7HLDC09IqAJDdOo4TWK4?usp=sharing
BPI-W3 Tools
Baidu cloud: https://pan.baidu.com/s/1SD3shbfQui4N19IVTXpmXQ?pwd=8888 Pincode: 8888
Google Drive: https://drive.google.com/file/d/1v1ixTDcjOqBPn6eyiNSH5yOBNWPUA8Ig/view?usp=sharing
