Banana Pi BPI-R3 Open Source Router Board Wi-Fi 6 & Dual Fiber SFP Ports

Banana Pi BPI-R3 Open Source Router Board Wi-Fi 6 & Dual Fiber SFP Ports

$91.51

Brand: Banana PI
Product Code: bpi-r3
Availability: In Stock
Ex Tax: $91.51
2 or more $89.27
4 or more $87.79

Tags: banana, pi, bpi-r3, open, source, router, board, wi-fi, 6, &, dual, fiber, sfp, ports, bpi-r3, routers, switches, &, ap

Description
Reviews (0)

Banana Pi BPI-R3 Open-Source Router

Banana Pi BPI-R3 Router board with MediaTek MT7986(Filogic 830) Quad-core ARM A53 + MT7531A chip design,2G DDR RAM,8 GB eMMC flash onboard. It is a very high-performance open-source router development board, supports Wi-Fi 6 2.4 GHz Wi-Fi using MT7975N and 5G wifi using MT7975P, supports 2 SFP 2.5GbE ports, and a 5 GbE network port.

MediaTek MT7986(Filogic 830)

The MT7986(Filogic 830) integrates four Arm Cortex-A53 cores up to 2GHz with up to 18,000 DMIPs of processing power and 6Gbps of dual 4x4 Wi-Fi6 connectivity. It has two 2.5 G Ethernet interfaces and serial peripheral interfaces (SPI). Filogic 830‘s built-in hardware acceleration engine enables fast and reliable Wi-Fi offloading and wireless network connection. In addition, the chip supports Mediatek FastPath™ technology, which is suitable for games, AR/VR, and other low-latency applications.

Wi-fi 6 has many advantages over its predecessors, including lower latency, larger bandwidth capacity, and faster transmission rates. Wireless network devices supporting the 6GHz band mainly use a 160MHz wide channel and 6GHz uncongested bandwidth to provide multigigabit transmission and low-latency wi-fi connection, providing a reliable wireless network for streaming media, games, AR/VR, and other applications.

Application direction

Maker DIY

Internet service Router

Wireless Router

Wireless Repeater

Home security Gateway

Home Automation

Nas device

Network and communication applications

Key Features

MediaTek MT7986(Filogic 830) Quad-core ARM Cortex A53+MT7531 chip design

Wifi 6 4x4 2.4G Wifi(MT7975N) +4x4 5G Wifi(MT7975P)

2G DDR RAM

8G eMMC flash

128MB SPI Nand

2x SFP 2.5GbE

5x GbE network port

Mini PCIe via USB

M.2 KEY-M PCIe interface

Micro SD card interface

26 PIN GPIO

POE function is customizable (the present version does not support the POE function)

Hardware Specification of Banana Pi BPI-R3

CPU MediaTek MT7986(Filogic 830) Quad-core ARM Cortex A53+MT7531 chip design

SDRAM 2 GB DDR4

On board Storage MicroSD $TF$ card,8GB eMMC onboard

GPIO 26 Pin GPIO, some of which can be used for specific functions, including UART, I2C, SPI, PWM, and I2S.

On board Network 5 Port 10/100/1000Mbps Ethernet

SFP 2 SFP 2.5GbE

Wifi Wifi 6 4x4 2.4G Wifi(MT7975N) +4x4 5G Wifi(MT7975P)

mini PCIE Mini PCIe via USB

M.2 interface M.2 KEY-M PCIe interface

USB 1 USB 3.0 host,2 USB interfaces with a slot.

Buttons: Reset button, WPS button, boot switch

LED Power status LED and RJ45 LED

DC Power 12V/2A with DC in

Sizes 100.5x148mm, same as Banana Pi BPI-R64 and Banana Pi BPI-R2

Weight 200g

System Image

OpenWRT

Latest official OpenWRT snapshot image:

https://firmware-selector.openwrt.org/?version=SNAPSHOT&target=mediatek%2Ffilogic&id=bananapi_bpi-r3

Discuss on OpenWRT forum: https://forum.openwrt.org/t/openwrt-support-for-banana-pi-bpi-r3/154294

2022-07-20 update BPI-R3 OpenWRT 21.02 Linux kernel 5.4, wifi 6 2.4G and 5G mac80211 opensource wifi driver working fine, supports NAND flash, SD card,eMMC flash boot. for BPI-R3 production version hardware

Google Drive: https://drive.google.com/file/d/13nQMfM0_XTyWcILhNxv_9E4TIvb65RI0/view?usp=share_link

Baidu Cloud: https://pan.baidu.com/s/1-5tqHEacMw1wlTSEK1ey9A?pwd=8888 (pincode: 8888)

2022-06-01udptae BPI-R3 OpenWRT 21.02 Linux kernel 5.4, wifi 6 2.4G and 5G working fine, supports NAND flash, SD card,eMMC flash boot. for BPI-R3 production version hardware

Google Drive: https://drive.google.com/file/d/18_xst-diDdCg7CeSum1M5FDbbo31jFJq/view?usp=drivesdk

Baidu link: https://pan.baidu.com/s/1idqU1-bB4XD1LTGDAJxRGA?pwd=chez Pincode: chez

Discuss on forum: https://forum.banana-pi.org/t/banana-pi-bpi-r3-openwrt-image/13236

2022-09-28 update BPI-R3 OpenWRT 21.02 Linux kernel 5.4, wifi 6 2.4G and 5G working fine, support NAND flash, SD card,eMMC flash boot, support EC25 LTE 4G
Modules for BPI-R3 production version hardware

Google Drive: https://drive.google.com/file/d/1oNcnIl8bDla9pPWUd-TFPXXphsCMsJt0/view?usp=sharing

Baidu link: https://pan.baidu.com/s/1v4sKfAuax3AfHNtp_2RP_g?pwd=mebq (Pincode: mebq)
