Orange Pi 4 LTS 4GB LPDDR4 Rockchip RK3399 Six Core ARMR 64 Bit with 16GB EMMC, Single Board Computer
$88.53
- Brand: Orange Pi
- Product Code: opi4-lts-4gb
- Availability: In Stock
- Ex Tax: $88.53
-
- 2 or more $87.04
- 4 or more $85.55
Orange Pi 4 LTS uses the Rockchip RK3399(28nm HKMG Process) and has 3 GB /4GB LPDDR4 SDRAM, and 16GB EMMC Flash（option）. It can run Android 8.1, Ubuntu16.04, Ubuntu18.04, and Debian9. Orange Pi 4 LTS offers a range of different ports, including HDMI output, 26pin headers, LCD connector, Gbps Ethernet port, 2*USB 2.0, 1*USB 3.0, 1*USB 3.0 TYPE-C, mini PCIE connector, etc. It is powered through DC and Type-C. It is a good choice for applications that need strong networking performance.
Hardware specification
SOC Rockchip RK3399 (4GB)
Rockchip RK3399-T(3GB)
CPU • Based on the large and small size of big.LITTLE core architecture:Dual-core Cortex-A72 (large core)+ Quad-core Cortex-A53(small core)
• 6-core ARMR64-bit processor ,main frequency speeds up to 1.6GHz(3GB)/1.8 GHz(4GB)
GPU • High-performance Multi-core Mali-T860 GPU
• Supports OpenGL ES1.1/2.0/3.0/3.1,OpenVG1.1,OpenCL,DX11
• Support for AFBC
PMU RK808 PMU
Memory 3 GB /4GB LPDDR4
Onboard Storage • 16GB EMMC Flash (option)
• MicroSD (TF) Card Slot
Onboard Ethernet Support 10/100M/1000M Ethernet (YT8531C)
Onboard WiFi+BT • CDW.20U5622-00
• Support IEEE 802.11 a/b/g/n/ac, 2T2R • Support BT 5.0
Video • HDMI 2. 0, Supports 4K@60fps output
• 1* DP 1.2(Display Port), Supports 4K@60fps output
• Supports Dual MIPl-DSI ( 4 lines Per Channel )
Audio • Output: 3.5mm Jack and HDMI2.0ainputput: MIC
Camera 2 * MIPI-CSl Camera Connector (MIPI_RXO、MIPI_TX1/RX1)
USB 2 * USB2.0 ,1*USB3.0,1 * USB3.0 Type-C
Debug UART 3-Pin
GPIO 26 Pin
PCIe Support Mini PCIe port
Key Upgrade Key & Reset Key
Power Supply DC 5V/3A or 5V/4A, TYPE-C 5V/4A
LED Power led & Status led
Supported OS Android, Ubuntu, Debian
