Orange Pi Zero 3 Allwinner H618 LPDDR4 Quad Core 64 Bit Single Board Computer, Support 4K Display WiFi Bluetooth
$20.53
- Brand: Orange Pi
- Product Code: opi-zero-3
- Availability: In Stock
- Ex Tax: $20.53
-
- 2 or more $19.05
- 4 or more $17.85
Available Options
About this item
The Orange Pi Zero 3 1Gb-1.5Gb-2Gb-4Gb uses a full-memory H618 64-bit high-performance quad-core Cortex-A53 processor, Arm Mali-G31 MP2 GPU, and supports OpenGL ES 1.0/2.0/3.2, OpenCL 2.0, Vulkan 1.1, etc.
Orange Pi Zero 3 1GB Microcontroller has four memory specifications of 1GB /1.5GB/2GB/4GB to choose from, supports a variety of video formats codec, Micro-HDMI output support 4K display, can be widely used in TV boxes, smart projection equipment and so on. Suitable for Building Mini PC/Smart Robot/Game Console/Workstation/Media Center/VR/Etc.
The Orange Pi Zero 3 Mini PC Computer can also extend the functions of headphones, TV-Out, USB2.0, and infrared reception through the 13Pin expansion port and adapter board.
The Orange Pi Zero 3 26Pin expansion function port on this board further enriches the functional interface of the motherboard and enhances the potential for development.
Orange Pi Single Board Computers can build a computer, a wireless server, Games, music and sounds, HD video, a speaker, Android, and Scratch. Pretty much anything else, because Orange Pi is open-source.
Product Specs
CPU Full memory H618 high-performance quad-core Cortex-A53 processor 1.5GHz
GPU Mali G31 MP2; Support OpenGL ES 1.0/2.0/3.2, OpenCL 2.0, Vulkan 1.1
Running Memory 1GB/1.5GB/2GB/4GB LPDDR4
Onboard Storage 16MB SPI Flash
Onboard WiFi+ Bluetooth Supports WiFi5 and Bluetooth 5.0
Network 10M/100M/1000M Ethernet interface
Audio Input and Output 13 The pin expansion port supports two outputs and one input.
Video Output Micro HDMI support 4K@60fps
Tv-Out 13Pin supports one TV CVBS output
UART 3Pin Debug UART
USB USB 2.0 x 3 (two of which lead from the expansion board)
SD Card Port MicroSD card port
Expansion Interface 26Pin GPIO interface; 13Pin GPIO interface
Power Input 5V3A, Type-c interface
Supported Operating Systems Android 12 TV, Debian11, Debian12, Ubuntu22.04, Ubuntu20.04
Product Size 50mmX55mm
