Banana Pi BPI-RV2 RISC-V Open Source Gateway Router Board OpenWRT
$39.14
- Brand: Banana PI
- Product Code: bpi-rv2
- Availability: In Stock
- Ex Tax: $39.14
-
- 2 or more $37.20
- 4 or more $35.72
Available Options
Banana Pi BPI-RV2 RISC-V Open Source Gateway Router Board OpenWRT - 1x 2.5G WAN 5x Gigabit LAN - 512MB DDR3 RAM - with Quad-core RISC-V CPU NPU Accelerator for Enterprise & Industrial
About this item
Siflower SF21H8898 SoC: The Banana Pi BPI-RV2 RSIC-V OpenWRT Open Source Smart Gateway Router Board is a Siflower SF21H8898 SoC-based device with 512MB DDR3 memory, 128 MiB NAND, 16 MiB NOR Memory, and supports PoE network power.
Industrial SoC Gateway: The Banana Pi BPI-RV2 Gateway Router Board is a high-performance industrial SOC gateway device that utilizes the advanced TSMC 12nm FFC process and integrates a quad-core 64-bit RSIC-V processor and a dedicated NPU network processing gas pedal (supporting L2/L3 hardware processing, IPv4/IPv6 dual stack, and 20Gbps switching capacity).
Stable Network Environment: The Banana Pi BPI-RV2 RSIC-V open-source gateway Router board on the network side supports QSGMII, SGMII/HSGMII, and RGMII outlets, and IEEE 1588 PTP for time synchronization, and NVMe SSDs (PCIe gen 2 x1) are supported on the M.2 2242/2230 outlets. Supports connection of SSD drives, 5G modules, WiFi modules, wired grid cards, etc.
Rich Interfaces: The Banana Pi BPI-RV2 Enterprise and Industrial Gateway Router Board is equipped with 1 × 2.5 Gigabit WAN network port, 5 Gigabit LAN ports, M.2 ports, MINI PCIE and USB 2.0 ports, MikroBUS expansion module sockets, and M.2 2242/2230 ports, etc.
Enterprise Gateway: BPI-RV2 RSIC-V is an open-source office home gateway router board supporting external DDR3/DDR3L/DDR4 SDRAM and NAND/NOR SPI Flash. High-speed ports include USB 2.0, PCIe 2.0, and low-speed ports include SPI, UART, I2C, and PWM. It can be used as an enterprise gateway or a workstation.
Product Description
Product Spec
SoC: Siflower SF21H8898 4 core RISC-V @ 1.25GHz
RAM: 512MB DDR3
Storage
128 MB SPI NAND Flash is used in U-Boot and Linux systems
16 MB SPI NOR flash， for U-boot and Linux systems, write protected by default (refresh can be enabled by jumper)
M.2 2242 interface support NVMe SSD hard disk (PCIe gen 2 x1)
Network
1 x 2.5GbE RJ45 port
5 x giga RJ45 port
USB
Use the USB Type-C (device, console) port of the UART to the USB chip
1x USB 2.0 Type-A USB HOST port
PCIE
M2 key B， Supported Rates PCIe gen 2 x1， Can be used to connect SSD hard drives, 5G modules, etc
MINI PCIE， Supported Rates PCIe gen 2 x1， Can be used to connect WiFi module, wired network card, etc
Extension
MikroBUS expansion module socket
Debug: Console connected via USB-C port or 3-pin connector
Others
Reset and user buttons
Boot choose：NAND（normal） Or NOR（Reset）(I2C interface)
Support the addition of an 802.3at/af PoE module
Size: 148 x 100.5 mm
Weight: 90g
Package Content
Banana Pi BPI-RV2 Router Board x1
OpenWrt
openwrt-siflower-sf21h8898-bpi-rv2-nand-squashfs-fullflash.img
Baidu cloud: https://pan.baidu.com/s/1iMbPKkwKE8es1hW1Zy6AGg?pwd=8888 (pincode:8888)
Google Drive: https://drive.google.com/file/d/1Szv0ARqT30inLvEWdtbdD-EcZanYq3Rp/view?usp=sharing
Openwrt-siflower-sf21h8898-bpi-rv2-nand-squashfs-sysupgrade.bin
Baidu Cloud: https://pan.baidu.com/s/1LL1mbWxmWMhUYw_-db9pMw?pwd=8888 (pincode:8888)
Google Drive: https://drive.google.com/file/d/1K2CJ0Uco6LmCNopPUk5Qn8fcHV5NQXmY/view?usp=sharing
